MOTECK CI10 Control Box

Control Box

CI10

Has a lever switch that opens and closes one actuator; also does not require a hand control.

Voltage24V DC

Motors controlled1

Duty cycle10%

Request a quote

Technical data

Technical specifications

Supply voltage: 110V AC 60 Hz / 230V AC 50 Hz (adjustable by slide switch)
Output voltage: 24V DC
Overload protection: 10 A max.
Power supply: 216 W (24V, 9 A) toroidal transformer
Max. number of actuators: 1 channel
No need for hand control
Emergency stop button
Equipped with a three-way switch for extend / retract / stop movement, which returns to its original position after releasing the button.
LED power indicator
Supports external battery (24V)
2nd output for supplementary device: 24V DC @ 350mA max.
Duty cycle: 10%, max. 2 min. continuous operation / 20 min.
Color: Pantone 432U
Power cable length: 3,000 mm
